Product Name : USB 3.0 B Type Female Right angle solder

Series : USB3.0; USB2.0; Micro USB; mini USB

Terminals : Copper Alloy( gold or tin plated)

Mounting type : straight solder;right angle;surface mount;solder cup; side solder

Insulator material : PBT; LCP; PA66 (UL94V-0)

Shell material : Steel&Copper Alloy(Ni plated)

Directions

Product information

Series	USB3.0; USB2.0; Micro USB; mini USB
Contact number	4pin; 5pin; 8pin; 9pin; 10pin; 12pin; 14pin
Mounting type	straight solder;right angle;surface mount;solder cup; side solder
Insulator material	PBT; LCP; PA66
Insulator Flammability	UL 94V-0
Shell material	Steel&Copper Alloy(Ni plated)
Terminal material	Copper Alloy( gold or tin plated)
Package	Tube package; Tape&reel package;Pallet package
Color	White;Black; Beige; Pure white
